What anti roll bars & tension arms are these ?

Want to know what to brakes/springs to buy?
User avatar
buttz
Trc On!
Posts: 59
Joined: Mon Oct 04, 2010 5:46 pm

What anti roll bars & tension arms are these ?

Postby buttz » Wed Jan 30, 2013 7:08 pm

went with a buddy there to pick up coilovers off a fella who was breaking an altezza and i noticed it had thicker anti roll bars front and rear so i went under the car to have a look and i also found out it had front tension arms whick i never seen on an altezza before so i said id buy the lot and got them for a handy 60euro for the lot :D

anybody no what make they are there a metallic red althought they were probably sprayed ?

front bar is around 30mm and rear is between 26-28mm

the coke cork is next to the rear roll bar
tension arms (go from front lca's to tow eyes)

User avatar
jfatboy
Tezza Fanatic!
Posts: 230
Joined: Wed Jun 27, 2012 9:09 pm

Re: What anti roll bars & tension arms are these ?

Postby jfatboy » Wed Jan 30, 2013 7:27 pm

they look like those really rare red ones ;)

they look no different to the kit i have on mine mate...

User avatar
mike_01
Altezza Guru
Posts: 1768
Joined: Mon Feb 07, 2011 12:32 pm
Location: Llanidloes

Re: What anti roll bars & tension arms are these ?

Postby mike_01 » Thu Jan 31, 2013 10:57 am

There uprated ones :mrgreen:
measure the diameter of the bar where the bushes are, or see if the bush has a number on them :wink:

ESXTEZZ
Tezza Fanatic!
Posts: 359
Joined: Sun Jan 30, 2011 12:46 pm
Location: Essex England
Contact:

Re: What anti roll bars & tension arms are these ?

Postby ESXTEZZ » Thu Jan 31, 2013 6:34 pm

The arms are made by Toms not sure about the arb`s

User avatar
buttz
Trc On!
Posts: 59
Joined: Mon Oct 04, 2010 5:46 pm

Re: What anti roll bars & tension arms are these ?

Postby buttz » Thu Jan 31, 2013 8:08 pm

I just measured sand the front is measuring at 31mm and the rear at 26mm if I'm right
Last edited by buttz on Fri Feb 01, 2013 1:36 pm, edited 1 time in total.

User avatar
mike_01
Altezza Guru
Posts: 1768
Joined: Mon Feb 07, 2011 12:32 pm
Location: Llanidloes

Re: What anti roll bars & tension arms are these ?

Postby mike_01 » Fri Feb 01, 2013 10:39 am

Not sure as the largest diameter I know of is
HOTCHKISS
Front 32mm
Rear 19mm

you sure you measured correct? what did you use?

User avatar
buttz
Trc On!
Posts: 59
Joined: Mon Oct 04, 2010 5:46 pm

Re: What anti roll bars & tension arms are these ?

Postby buttz » Fri Feb 01, 2013 1:48 pm

I'm wrapping tape around the bars and were they over lap I'm slicing with a Stanley blade ,
I can't get my hands on a vernier calliper so it's the only way I can do it


Rear circumferance is 83mm divide by 3.14 and I'm gettin 26.43mm
Front is 98mm divide by 3.14 and I'm gettin 31.21mm

User avatar
buttz
Trc On!
Posts: 59
Joined: Mon Oct 04, 2010 5:46 pm

Re: What anti roll bars & tension arms are these ?

Postby buttz » Mon Feb 11, 2013 10:52 pm

Any body else have info on the roll bars?

I fitted the rear one and the differance is unreal body roll is almost eliminated

User avatar
NinjaPower
Trc Off
Posts: 84
Joined: Sun Jan 13, 2013 12:38 am
Location: Surrey UK

Re: What anti roll bars & tension arms are these ?

Postby NinjaPower » Tue Feb 12, 2013 12:00 am

Those adjustable arms arnt tension rods.. They are TOM's strengthening bars.. They go from the tow eyes at the front to the chassis leg where the ARB is. I have an absolutely mint pair from my old Altezza if anyone wants them. I had the full set of 3 of the TOM's strengthening bar kits but never sold this pair.
Think I saw them once all listed on BulletproofAutomotive, not sure if they are still there or not..

For reference, tension rods are the kinked bars that go from the lower arm to the chassis..

ESXTEZZ
Tezza Fanatic!
Posts: 359
Joined: Sun Jan 30, 2011 12:46 pm
Location: Essex England
Contact:

Re: What anti roll bars & tension arms are these ?

Postby ESXTEZZ » Tue Feb 12, 2013 1:56 pm

NinjaPower wrote:Those adjustable arms arnt tension rods.. They are TOM's strengthening bars.. They go from the tow eyes at the front to the chassis leg where the ARB is. I have an absolutely mint pair from my old Altezza if anyone wants them. I had the full set of 3 of the TOM's strengthening bar kits but never sold this pair.
Think I saw them once all listed on BulletproofAutomotive, not sure if they are still thee or not..

For rrence, tension rods are the kinked bars that go from the lower arm to the chassis..



PM me a price mate for the toms bars mate.
The ARB's are not hotchkis as hothchkis are adjustable, they look like tanabe
